Aung Metals, based in Naypyidaw, Myanmar, stands out as a top manufacturer and supplier of high-quality Monel 400 Forgings. Renowned for its precision engineering and unwavering commitment to excellence, Aung Metals provides high-performance nickel-copper alloy products that adhere to international standards, making them perfect for demanding industrial applications. Their Monel 400 Forgings are crafted for outstanding corrosion resistance, mechanical strength, and durability, which makes them ideal for tough and high-stress environments. Thanks to advanced manufacturing techniques, rigorous quality control, and prompt delivery, Aung Metals guarantees reliable, long-lasting materials that deliver exceptional performance and value, solidifying its reputation as a trusted supplier of specialty alloys in Myanmar and beyond.
Monel 400 Forgings are nickel-copper alloys that typically consist of about 63% nickel, 28–34% copper, along with trace amounts of iron and manganese. In terms of mechanical properties, these forgings boast a tensile strength ranging from 550 to 700 MPa, a yield strength of 240 to 400 MPa, and an elongation of 30 to 50%. This combination provides excellent toughness, ductility, and wear resistance. Their unique composition ensures remarkable resistance to corrosion, oxidation, and stress cracking in both acidic and alkaline environments, making them perfect for critical components that face harsh industrial and marine conditions.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel 400 Forging UNS (N04400), DIN (2.4360)
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Density | Melting Range | Curie Temperature | Electricity Resistivity | |||
| g/cm3 | lb/in3 | °F | °C | °F | °C | µΩ·m |
| 8.8 | 0.318 | 2370-2460 | 1300-1350 | 70-120 | 21-49 | 547 |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Temperature control is crucial in forging Monel 400, ensuring optimal mechanical properties, preventing defects, and maintaining its corrosion resistance and strength. Proper control minimizes cracking and enhances overall quality.
Assess Monel 400's forging strength for aerospace by evaluating its tensile strength, yield strength, and fatigue resistance under simulated operating conditions. Conduct tests for thermal stability and corrosion resistance to ensure suitability.
Evaluate Monel 400 forgings by checking their mechanical properties, corrosion resistance, and compatibility with your operating environment. Review certifications, standards, and conduct application-specific testing for assurance.
Monel 400 Forgings find extensive applications in chemical processing, marine engineering, desalination plants, and the aerospace industry, thanks to their exceptional corrosion resistance and mechanical performance. They are particularly well-suited for manufacturing pumps, valves, shafts, fittings, and heat exchangers that are exposed to seawater or aggressive chemicals. Moreover, these forgings are also used in structural components and industrial machinery that demand high durability, wear resistance, and long-term reliability. The blend of strength, corrosion resistance, and toughness makes Monel 400 Forgings the go-to choice for high-performance and demanding engineering applications.
Monel 400 forgings are widely used in industries that require high strength and resistance to corrosion. Common applications include marine environments, where they are used for seawater pumps, propeller shafts, and valves. They are also found in chemical processing equipment, such as heat exchangers and reactors, due to their excellent resistance to acids and alkalis. Additionally, Monel 400 is used in aerospace components, such as turbine engines and cryogenic systems, as well as in oil and gas industries for valves and pipes.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
