Aung Metals is a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, specializing in top-notch Super Duplex Steel S32760 Forgings. These forgings are crafted for exceptional strength, durability, and resistance to corrosion, making them perfect for tough environments. With their impressive blend of mechanical strength and chemical stability, they promise a reliable service life and maintain structural integrity. Aung Metals produces S32760 Forgings that meet rigorous international standards, making them a go-to choice for critical sectors like oil and gas, chemical processing, marine, and power generation, where outstanding performance is a must.
Super Duplex Steel S32760 Forgings are primarily composed of chromium (25%), nickel (7%), and molybdenum (3.6%), along with small amounts of copper, tungsten, and nitrogen to boost strength and corrosion resistance. They boast remarkable mechanical properties, featuring a tensile strength of 800–850 MPa, a yield strength of 550 MPa, and an elongation of about 25%. The alloy’s duplex microstructure grants it excellent toughness, hardness, and fatigue resistance, ensuring it performs exceptionally well under high pressure and temperature while remaining reliable and durable in tough conditions.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
Aung Metals’ Super Duplex Steel S32760 Forgings are extensively utilized in industries that require high resistance to corrosion and stress. They’re perfect for offshore oil and gas platforms, subsea equipment, chemical processing systems, and desalination plants. Their outstanding resistance to pitting, crevice corrosion, and chloride stress corrosion cracking makes them ideal for marine and seawater applications. Additionally, they find use in pressure vessels, heat exchangers, and pumps where strength and reliability are crucial. These forgings guarantee optimal performance in aggressive, high-stress, and corrosive operational settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aung Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Naypyidaw, Myanmar
