Aung Metals, a reputable manufacturer and supplier located in Naypyidaw, Myanmar, is all about crafting top-notch Carbon Steel EN-9 Bars that are built for strength, durability, and precision. Thanks to their cutting-edge manufacturing techniques and strict quality control measures, Aung Metals guarantees that each EN-9 Bar not only meets international standards but also performs reliably across a variety of industrial applications. These bars are celebrated for their impressive tensile strength, hardness, and wear resistance, making them perfect for the automotive, machinery, and engineering sectors. Aung Metals delivers precision-engineered steel solutions that blend toughness, machinability, and long-lasting performance, making them the go-to choice for demanding industrial and mechanical tasks.
Carbon Steel EN-9 Bars are medium-carbon steels that typically contain around 0.36–0.44% carbon, 0.60–0.90% manganese, along with trace amounts of phosphorus and sulfur. This unique blend results in a well-rounded mix of strength, toughness, and wear resistance. On the mechanical side, EN-9 steel boasts a tensile strength of about 600–700 MPa and a yield strength ranging from 355–450 MPa. It’s known for its good machinability, moderate ductility, and outstanding hardness, and it can be heat-treated to boost its mechanical performance in tough engineering applications.
| Grade | 070M55 / EN-9 |
|---|---|
| Specification | BS 970 1991 |
| Round Bar Size | Diameter: 3-~800mm |
| Square Bar size | 4 to 100mm |
| Flat Bar Size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hex Bar Size | 2-100mm A/F |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, Rough Turned, Bright, peeled, hot rolled, hot rolled annealed, slit rolled edge, Polish, Grinding, Centreless Ground & Black |
| Tolerance | K9, K10, K11, K12, H8, H9, H10, H11, H12, H13, or as per clients’ requirements |
| Surface | Polished, Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Hairline |
| Condition | Hardened & Tempered, Annealed |
| Technique | en9 Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rods |
| Processing | Bar cutting to 650mm |
| Form | en9 Welding Rod, Round, Round Rod, Rings, Hollow, Rod, T-Bar, Channel Bar, Flat Bar, Square, Blocks, Precision Ground Bar, Triangle, Rectangle, Hex (A/F), Threaded, Ingot, I/H Bar, Half Round Bar, Profiles, Billet, Forging etc. |
| EN9 / 070M55 Bars and Rods Conforms To NACE MR0175/ISO 15156 | |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| Standard | CS EN-9 |
| UNS | – |
| WERKSTOFF NR. | CK55 |
| BS | 070M55 |
| IS | C55 |
| JIS | – |
| EN | EN9 |
| SAE/AISI | 1055 |
Carbon Steel EN-9 is commonly used for manufacturing bolts, nuts, fasteners, and structural components in heavy-duty applications like automotive and construction industries.
EN-9 offers excellent tensile strength, wear resistance, and hardenability, making it suitable for components subjected to mechanical stresses and heavy-duty environments.
Yes, Carbon Steel EN-9 can be heat-treated to enhance its hardness and strength, making it versatile for various engineering applications.
These Carbon Steel EN-9 Bars are a staple in the automotive, mechanical, and general engineering industries, thanks to their remarkable strength, hardness, and versatility. You’ll find them in a variety of applications, including shafts, bolts, studs, axles, gears, crankshafts, and connecting rods, all of which demand durability and wear resistance. They’re also utilized in construction equipment, agricultural machinery, and forging operations where toughness and dimensional stability are essential. With their excellent machinability and responsiveness to heat treatment, EN-9 Bars are perfect for crafting precision-engineered components that can withstand high-stress and heavy-duty operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aung Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Naypyidaw, Myanmar
