Aung Metals, based in Naypyidaw, Myanmar, has built a solid reputation as a manufacturer and supplier of top-notch Monel 400 Bars and Rods. With a keen emphasis on precision, durability, and keeping customers happy, Aung Metals delivers products that not only meet international standards but also serve a variety of industrial needs. Thanks to their state-of-the-art manufacturing facilities and a team of skilled professionals, they ensure that quality and performance are always consistent. Monel 400 Bars and Rods from Aung Metals are highly regarded for their remarkable strength, resistance to corrosion, and reliability, making them the go-to choice for industries that require high-quality nickel-copper alloy materials in tough environments.
These Monel 400 Bars and Rods are made up of about 67% nickel and 30% copper, along with trace amounts of iron, manganese, silicon, and carbon. This solid-solution alloy is known for its excellent resistance to seawater, acids, and alkaline conditions. It boasts a high tensile strength of around 550 MPa, a good yield strength close to 240 MPa, and impressive toughness across a wide range of temperatures. Monel 400 retains its mechanical properties even in extreme cold and high heat, offering outstanding ductility, weldability, and corrosion resistance, which makes it perfect for harsh and corrosive industrial settings.
| Standard | ASTM B164, ASME SB164 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | BS | EN |
| Monel 400 | 2.4360 | N04400 | МНЖМц 28-2,5-1,5 | NU-30M | NW 4400 | NA 13 | NiCu30Fe |
Yes, Monel Alloy 400 Bars are highly corrosion-resistant, especially in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions.
Yes, Monel 400 rods can be customized in size and length according to specific requirements. They are available in various diameters and lengths to suit different industrial applications.
Monel Alloy 400 Bars and Rods perform well in high-temperature environments, maintaining strength and resistance to oxidation. They can withstand temperatures up to 1,000°F (538°C) without significant degradation.
You’ll find Monel 400 Bars and Rods being widely used in marine engineering, chemical processing, oil and gas, and power generation industries. Their exceptional resistance to seawater and acidic solutions makes them perfect for crafting pump shafts, valves, heat exchangers, and piping systems. In the aerospace and defense fields, they’re utilized in structural components that require both high strength and corrosion resistance. These bars and rods are also essential in desalination plants and offshore platforms. Aung Metals’ Monel 400 Bars and Rods promise long-lasting performance, reliability, and durability, even in the most challenging operational environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
