Aung Metals is a reliable manufacturer and supplier of Monel Bars and Rods, located in Naypyidaw, Myanmar. They specialize in providing top-notch nickel-copper alloy solutions for a variety of industrial needs. The company prides itself on precision manufacturing, rigorous quality control, and adherence to international standards, ensuring that their products boast exceptional strength, durability, and resistance to corrosion. Monel Bars and Rods are highly regarded for their impressive mechanical properties, toughness, and ability to endure harsh and corrosive environments. With a commitment to timely delivery, competitive pricing, and outstanding customer support, Aung Metals caters to industries such as marine, chemical, aerospace, power generation, and heavy engineering, offering reliable and high-performance Monel alloy products.
Monel Bars and Rods are primarily made up of nickel and copper, with small amounts of iron and manganese, which contribute to their remarkable corrosion resistance, strength, and toughness. These bars showcase high tensile strength, good ductility, and excellent resistance to pitting, crevice corrosion, and stress-corrosion cracking. Monel maintains its dimensional stability and mechanical integrity even in high temperatures and aggressive chemical settings. Its well-balanced composition guarantees long-lasting durability, impressive mechanical performance, and dependable operation in tough industrial conditions, making it ideal for applications where both corrosion resistance and high strength are essential.
Monel Round Bar Specification : ASTM B164 / A479, ASME SB164 / A479
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| 400 | 63.0- 70.00 max | 2.50 max | 0.3 max | 2.00 max | 0.50 max | Remainder | – | – | 0.024 max |
| K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.35 – 0.85 | 0.010 max |
| Grade | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
|---|---|---|---|---|
| 400 | 75 to 90 | 25 to 50 | 60 to 35 | 60 to 80 |
| K500 | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15,000 , MPa – 790 | 20 % | – |
| STANDARD | UNS | WNR. | JIS | EN |
|---|---|---|---|---|
| Monel 400 | N04400 | 2.4360 | NW 4400 | NiCu30Fe |
| Monel K500 | N05500 | 2.4375 | – | – |
Yes, Monel alloy bars are highly corrosion-resistant, particularly to seawater, acids, and alkalis. Their exceptional resistance makes them suitable for harsh environments and applications requiring durability.
Yes, Monel rods can be customized in size and length to meet specific application requirements. They are available in various diameters and lengths, ensuring versatility for different industries.
Monel alloy bars and rods perform excellently in high-temperature environments, maintaining strength and resistance to oxidation. They are ideal for applications in extreme heat, such as chemical processing and marine industries.
Monel Bars and Rods find extensive use in industries that demand materials capable of withstanding corrosive, high-stress, and marine environments. They are often utilized in marine applications for shafts, propellers, pumps, and seawater-handling equipment. In the realm of chemical processing, Monel bars are employed in heat exchangers, piping systems, and reaction vessels. The alloy is also well-suited for aerospace, oil and gas, and high-performance mechanical components that face harsh operating conditions. Its unique blend of toughness, corrosion resistance, and mechanical strength makes Monel an excellent choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
