Aung Metals, one of the prominent and leading manufacturers and suppliers in the Naypyidaws region of Myanmar, is recognized for commitment to excellence in producing premium quality stainless steel products, especially Stainless Steel 316L Square Bars and Rods, that offer very good corrosion resistance, along with strength and durability, and are extensively used by various industries in the chemical, marine, and food processing sectors. We pay strict attention to detail to give our customers the precise, reliable solution they deserve with every order. Our commitment is to offer excellent products that meet the strict standards of the industry, ensuring long-term durability and customer satisfaction at Aung Metals.
The chemical composition of Stainless Steel 316L Square Bars and Rods consists of about 16-18% chromium, 10-14% nickel, and 2-3% molybdenum with low carbon content. It offers a great improvement in the corrosion resistance in chlorides. Mechanical properties comprise a tensile strength of up to 580 MPa, a yield strength of up to 240 MPa, and good weldability. Some of the benefits include excellent corrosion resistance, especially against pitting and crevice corrosion, excellent formability, and improved durability in extreme environments. They are ideal for marine, chemical, and pharmaceutical applications because they offer longevity, low maintenance, and superior performance in aggressive conditions.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316l | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 Min | 170 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316l | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 316L Square Bars are highly corrosion-resistant, especially to pitting and crevice corrosion in chloride environments. This makes them ideal for marine and chemical applications.
Stainless Steel 316L square bars are generally non-magnetic in their annealed state. However, they may exhibit slight magnetism when cold worked.
Yes, Stainless Steel 316L square bars are suitable for heat exchangers due to their excellent corrosion resistance, high-temperature stability, and good weldability. They are ideal for applications in corrosive and high-temperature environments.
Stainless steel 316L square bars are available for those industries that require excellent corrosion resistance in marine, chemical, food processing, etc. Its carbon content is low. Hence, weldability is good, with pitting, crevice, and many more corrosion resistances. Major applications include structural components, fasteners, valves, pumps, equipment designed to be used in extreme environments, etc. They are also used for the production of biocompatible components in the pharmaceutical and medical industries as well as for architectural applications. There is a great resistance provided by the material to aggressive chemicals and high temperatures. Thus, it is very useful in various industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
