Aung Metals, located in Naypyidaw, Myanmar, has built a solid reputation as a reliable manufacturer and supplier of top-notch stainless steel products, including their Stainless Steel 15-5 PH Bars/Rods. Known for their precision engineering and durability, Aung Metals meets a wide range of industrial needs with a strong commitment to excellence. The company places a high priority on quality control, ensuring that every bar and rod adheres to international standards. With state-of-the-art production facilities and a team of skilled professionals, Aung Metals consistently delivers dependable stainless steel products, making them a go-to choice for manufacturers, engineers, and fabricators not just in Myanmar, but beyond. Their Stainless Steel 15-5 PH Bars/Rods are particularly recognized for their outstanding performance and longevity.
These Stainless Steel 15-5 PH Bars/Rods are primarily made of iron, featuring 15% chromium, 5% nickel, and trace amounts of copper, manganese, and carbon, which together provide excellent corrosion resistance and strength. This type of precipitation-hardening stainless steel boasts impressive tensile strength, typically around 1,300 MPa, and a yield strength close to 1,150 MPa, along with good elongation of 10–12%. It offers remarkable toughness, fatigue resistance, and dimensional stability even under stress. The alloy can be heat-treated to boost its hardness and mechanical performance, making it ideal for demanding engineering applications where both strength and corrosion resistance are crucial.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
Stainless Steel 15-5 PH Bars/Rods find extensive use in industries such as aerospace, chemical processing, petrochemical, and power generation, thanks to their high strength, corrosion resistance, and toughness. They are perfect for crafting shafts, fasteners, valves, gears, and structural components that face high stress or harsh environments. Additionally, they are frequently used in marine and cryogenic applications, where durability and corrosion resistance are vital. Their versatility allows engineers to incorporate them into both precision machinery and heavy-duty industrial equipment, making Stainless Steel 15-5 PH Bars/Rods from Aung Metals a valuable asset in various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aung Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Naypyidaw, Myanmar
