Aung Metals, a top-notch manufacturer and supplier located in Naypyidaw, Myanmar, specializes in high-quality **Stainless Steel 904L Hex Bars**. These bars are celebrated for their outstanding corrosion resistance, mechanical strength, and durability. Crafted with precision and in line with international standards, they deliver dependable performance even in the most corrosive and demanding industrial settings. Thanks to their high nickel, chromium, and molybdenum content, Stainless Steel 904L offers remarkable protection against pitting, crevice corrosion, and stress corrosion cracking. Aung Metals’ 904L Hex Bars are perfect for use in chemical processing, marine engineering, oil and gas, and power generation, ensuring long-lasting operational efficiency and structural integrity.
These hex bars are made up of about 20–23% chromium, 25–28% nickel, 4–5% molybdenum, along with trace amounts of copper and manganese, which contribute to their excellent resistance to corrosion and oxidation. They boast impressive mechanical properties, including a tensile strength ranging from 500–700 MPa, yield strength of 215–275 MPa, and elongation of 35–45%. The material is known for its good hardness, toughness, and weldability, making it reliable in high-pressure, high-temperature, and chemically aggressive environments—ideal for critical industrial applications.
| Specifications | ASTM B649 / ASME SB 649 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Stainless Steel Round Bar | Outside Diameter in the range of 4mm to 500mm |
| Stainless Steel Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Stainless Steel Hex Bar | 18mm – 57mm (11/16″ to 2-3/4″) |
| Stainless Steel Square Bar | 18mm – 47mm (11/16″ to 1-3/4″) |
| Stainless Steel Flat Bar | 1/2″ to 10″ in thickness range of 2 mm to 150mm, Custom Size Stainless Steel Flats available |
| Range | 3.17 MM TO 350 MM DIA |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Finishing | Bright, Polish & Black |
| Form of | Hex, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Other Services | Machining (CNC), Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polish, Rolling, Forging, Cutting, Bending, Minor Fabrication, |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 904L Hex Bar offers excellent corrosion resistance, especially against pitting, crevice, and stress corrosion cracking. Its high nickel and chromium content make it ideal for harsh environments like chemical processing, marine, and power plants. The hexagonal shape provides enhanced strength and machinability, ensuring durability and reliability in industrial applications.
SS 904L outperforms many stainless steels, such as 304 and 316, in corrosion resistance due to its higher nickel and molybdenum content. This composition enhances resistance to chloride-induced pitting and crevice corrosion, making it ideal for environments with high chloride concentrations or acidic exposure, such as chemical and marine applications.
SS 904L Hex Bar is commonly used in the chemical, petrochemical, marine, and pharmaceutical industries. It is ideal for applications such as heat exchangers, reactor vessels, pressure vessels, and piping systems, where resistance to corrosion, especially in acidic and chloride-rich environments, is critical for long-term durability and performance.
Aung Metals’ Stainless Steel 904L Hex Bars are widely utilized in sectors where high corrosion resistance and mechanical strength are crucial. They are particularly suited for chemical and petrochemical processing equipment, heat exchangers, pumps, valves, and marine applications. Moreover, they are employed in structural components that face strong acids, chlorides, and other harsh environments. With their exceptional durability, precise dimensions, and resistance to pitting and crevice corrosion, these hex bars promise a long service life and dependable performance in challenging industrial and engineering tasks.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
