Aung Metals is a renowned supplier, manufacturer, and exporter of SS 310s Hex Bars, widely recognized as one of the most extensively used grades of heat-resistant stainless steel across various industrial sectors. Stainless Steel 310s Hex Bars are medium-carbon austenitic stainless steel, designed for high-temperature applications such as furnace components and heat treatment equipment. These bars offer excellent resistance to oxidation, performing effectively at temperatures up to 2010°F (1100°C) under moderately cyclic conditions.
SS 310S hex bars/rods are made from stainless steel alloy, primarily composed of 25% chromium and 20% nickel, with small amounts of carbon, manganese, and silicon. This composition provides excellent resistance to oxidation and corrosion, especially at high temperatures. SS 310S offers superior strength, durability, and excellent weldability. It maintains its mechanical properties in extreme environments, including resistance to scaling and thermal fatigue. It is commonly used in industries like petrochemical, furnace, and heat treatment applications, where high temperature and corrosion resistance are crucial.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 310s | 0.08 max | 24.0 – 26.0 | 2.00 max | 19.0 – 22.0 | 0.045 max. | 0.03 max. | 1.50 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 310s | 8 | 1400 ℃ | 515 MPa | 205 | 40 – 50 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 310S hex bars/rods are primarily used in high-temperature applications, such as furnace components, heat exchangers, and petrochemical industries. They are also employed in the manufacturing of furnace parts, chimney liners, catalytic reactors, and welding electrodes due to their excellent oxidation, corrosion resistance, and strength at elevated temperatures.
SS 310S offers superior corrosion resistance compared to many other stainless steel grades, especially at high temperatures, due to its higher chromium and nickel content. It excels in resisting oxidation and scaling at temperatures up to 1100°C (2012°F), making it more heat-resistant than grades like SS 304 or SS 316.
Common manufacturing processes for SS 310S hex bars/rods include hot rolling, cold drawing, and extrusion. These methods shape the alloy into hexagonal rods while maintaining its mechanical properties. Heat treatment processes like annealing are also used to enhance corrosion resistance and improve the material's strength and ductility.
SS 310S hex bar/rods are widely used in hot and humid environments due to their exceptional resistance to oxidation and scaling Commonly found in furnace components, heat exchangers and petrochemical applications. These rods are also used in the manufacture of industrial furnace parts, catalytic reactors and chimney linings. Their excellent weldability and strength make them ideal for high pressure applications. In addition, SS 310S is used in the manufacture of welding electrodes and in applications requiring resistance to thermal fatigue and corrosion at elevated temperatures
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
