Aung Metals, located in Naypyidaw, Myanmar, has built a solid reputation as a manufacturer and supplier of top-notch metal products, including Aluminium 5082 Bars and Rods. With a focus on precision engineering, cutting-edge production facilities, and a commitment to international quality standards, the company delivers aluminium solutions that are known for their strength, durability, and impressive corrosion resistance. The Aluminium 5082 Bars and Rods from Aung Metals are perfect for applications that demand reliability, especially in tough or marine environments. Catering to industries like shipbuilding, automotive, structural fabrication, and chemical processing, Aung Metals guarantees consistent performance, a long service life, and customer-centric solutions designed to meet a variety of industrial needs.
These Aluminium 5082 Bars and Rods are primarily made from an aluminium alloy containing 4.0–4.5% magnesium, along with small amounts of chromium and manganese, which boost their corrosion resistance and strength. This alloy boasts a tensile strength of about 230–330 MPa, a yield strength of around 125–260 MPa, and an elongation of 10–20%, depending on the temper. Additionally, Aluminium 5082 is known for its excellent weldability, good fatigue resistance, and stability in marine and chemical settings, making it ideal for applications that require both durability and lightweight properties.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Al | Cr | Cu | Fe | Mg | Mn | Si | Ti | Zn | Residuals |
| 5082 | 95.2 to 98.3% | 0.25% max | 0.1% max | 0.5% max | 0.6 to 1.2% | 0.4% to 1.0% | 0.7 to 1.3% | 0.1% max | 0.2% max | 0.15% max |
| Density | Melting Point | Modulus of Elasticity | Electrical Resistivity | Thermal Conductivity | Thermal Expansion | Specific Heat |
| Value | 2700 kg/m3 | 555°C | 70 GPa | 0.038×10-6 Ω.m | 180 W/m.K | 24×10-6 /K |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5 | AG4,5 | 3.3345 | A95082 | AlMg4,5 | 5082 | AlMg4,5 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Maintain Aluminum 5082 bars by regularly cleaning with mild soap and water to prevent dirt buildup. Avoid harsh chemicals, use non-abrasive tools, and protect against corrosion by storing in dry conditions.
Yes, Aluminium 5082 bars are recyclable. Like most aluminum alloys, they can be melted down and reused without significant loss of properties, making them an environmentally sustainable material.
Yes, Aluminium 5082 rods can be customized in size and length. Manufacturers often offer custom dimensions to meet specific requirements for industrial, construction, or engineering applications.
Aluminium 5082 Bars and Rods are extensively used in marine and offshore applications due to their outstanding resistance to seawater, making them suitable for boat hulls, marine fittings, and dock structures. They also find their place in automotive components, fuel tanks, pressure vessels, storage tanks, and structural frameworks that are exposed to corrosive environments. Furthermore, they are favored in chemical processing equipment and architectural fabrication where performance and longevity are crucial. The alloy’s exceptional corrosion resistance, strength, and workability make Aluminium 5082 Bars and Rods a dependable choice for demanding industrial and engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
