Aung Metals, based in Naypyidaw, Myanmar, has built a solid reputation as a manufacturer and supplier of top-notch Aluminium 7075 Bars and Rods. They pride themselves on delivering high-quality materials that meet the rigorous standards of various industries. Renowned for their exceptional strength, precision, and durability, Aung Metals serves a wide range of sectors that rely on lightweight and dependable metal solutions. The company places a strong emphasis on quality assurance, ensuring accurate material composition and timely delivery to support the aerospace, defense, automotive, and engineering fields. With a focus on customer satisfaction and adherence to international standards, Aung Metals offers Aluminium 7075 Bars and Rods that excel in high-stress and critical applications.
Aluminium 7075 Bars and Rods are primarily made of aluminium, with zinc as the key alloying element, along with trace amounts of magnesium, copper, and chromium. This unique combination gives the material impressive tensile strength, excellent fatigue resistance, and remarkable hardness. Compared to many other aluminium grades, Aluminium 7075 boasts superior mechanical properties while still being relatively lightweight. It can also be heat-treated to boost its performance and is known for its good machinability. However, its corrosion resistance is moderate, so applying protective coatings is advisable in environments that require extra durability.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is commonly used for structural applications due to its high strength, excellent corrosion resistance, and lightweight properties, making it suitable for aerospace, automotive, and military structural components.
Aluminium 7075 rods are sized based on their diameter and length. Diameters typically range from 1/8" to 12", and lengths vary from 3' to 20', depending on specific customer requirements.
To maintain Aluminium 7075 bar, regularly clean it with mild soap and water to remove dirt. Avoid harsh chemicals, and store it in a dry, cool environment to prevent corrosion and damage.
These Aluminium 7075 Bars and Rods are widely sought after in applications that demand a high strength-to-weight ratio and outstanding mechanical stability. They are extensively used in the aerospace and aviation sectors for aircraft fittings, structural components, and frames. In the automotive and motorsport industries, they find their place in high-performance engine parts, drive shafts, and suspension components. Defense applications include weapon parts, armor plate fittings, and tactical gear. Additionally, these rods are popular in sports equipment, such as bicycle frames, climbing gear, and archery components, where strength, reliability, and performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
