Aung Metals, located in Naypyidaw, Myanmar, has built a solid reputation as a manufacturer and supplier of top-notch metal products, particularly Aluminium 5086 Bars and Rods. Thanks to their state-of-the-art production facilities, skilled workforce, and rigorous quality control, the company guarantees that its aluminium offerings meet international standards. The Aluminium 5086 Bars and Rods from Aung Metals are well-known for their outstanding corrosion resistance, impressive strength, and durability, making them perfect for tough industrial settings. They cater to various sectors, including marine, automotive, construction, and chemical processing, and are dedicated to providing dependable, long-lasting aluminium solutions that meet a wide range of application needs.
These Aluminium 5086 Bars and Rods are primarily made from aluminium alloyed with 3.5–4.5% magnesium, along with trace amounts of chromium and manganese to boost strength and corrosion resistance. They boast mechanical properties like a tensile strength of 240–330 MPa, yield strength of 150–270 MPa, and an elongation of about 12–20%, depending on the temper. This alloy is known for its excellent weldability, high fatigue resistance, and superior performance in marine and chemically harsh environments, making it ideal for structural and load-bearing applications where durability and reliability are crucial.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Si | Ir | Cu | Mn | Mg | Cr | Zn | Ti | Others, each | Others, total | Al |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20-0.70 | 3.5-4.5 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Balance |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4 | AG4MC | 3.3545 | A95086 | AlMg4 | 5086 | AlMg4Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5086 bars are fully recyclable. Aluminium is a sustainable material that can be recycled repeatedly without losing its properties, making it an environmentally friendly option for various applications.
Yes, Aluminium 5086 bars and rods can be used for potable water applications due to their corrosion resistance and durability, making them suitable for marine environments and water treatment systems.
When installing Aluminium 5086 bars and rods, consider factors such as proper handling to avoid damage, ensuring compatibility with other materials, and protecting against corrosion by using appropriate coatings or finishes.
Aluminium 5086 Bars and Rods find extensive use in marine and offshore applications, such as boat hulls, shipbuilding components, dock structures, and underwater equipment, thanks to their remarkable resistance to seawater corrosion. They are also employed in automotive frames, pressure vessels, fuel tanks, storage tanks, bridges, and welded structural assemblies. The combination of a high strength-to-weight ratio and corrosion resistance makes this alloy perfect for environments that face moisture, chemicals, and mechanical stress. These attributes ensure a long service life, making Aluminium 5086 a go-to material for demanding industrial and structural applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
