Aung Metals, located in Naypyidaw, Myanmar, stands out as a top-notch manufacturer and supplier of high-quality **Aluminium 6061 Bars and Rods**. Known for their precision, reliability, and commitment to international standards, Aung Metals delivers aluminium products that boast strength, corrosion resistance, and excellent machinability. Aluminium 6061, a heat-treatable alloy enriched with magnesium and silicon, is highly regarded for its versatility, lightweight nature, and durability. Thanks to advanced manufacturing techniques and rigorous quality control, Aung Metals guarantees that its Aluminium 6061 Bars and Rods consistently perform well across various sectors, including aerospace, automotive, construction, and engineering.
These Aluminium 6061 Bars and Rods primarily consist of aluminium, with magnesium (0.8–1.2%) and silicon (0.4–0.8%) as the key alloying elements, along with trace amounts of copper, chromium, and other elements. This unique blend offers remarkable corrosion resistance, good thermal conductivity, and a high strength-to-weight ratio. In terms of mechanical properties, the alloy boasts a tensile strength of about 290–310 MPa, a yield strength of around 240 MPa, and impressive elongation, making it perfect for machining, forming, and structural applications that demand both strength and lightweight features.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96061 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 | AA6061 | 3.3211 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6061 rods can be customized in size and length according to specific requirements. Manufacturers offer tailored solutions to meet the precise needs of various applications and industries.
To maintain Aluminium 6061 bars, regularly clean with mild soap and water, avoid harsh chemicals, inspect for damage, and store in dry, cool conditions to prevent corrosion and surface wear.
Yes, Aluminium 6061 bars are highly recyclable. Recycling this material preserves its properties, reduces energy consumption, and minimizes environmental impact, making it an eco-friendly choice for various industries.
Aluminium 6061 Bars and Rods are extensively utilized in industries where strength, corrosion resistance, and lightweight attributes are crucial. They are particularly suited for aerospace components, automotive parts, marine fittings, and structural frameworks. Moreover, they are also employed in pipelines, hydraulic systems, machinery components, and architectural projects due to their excellent machinability, weldability, and surface finish. With Aluminium 6061 Bars and Rods, you get a reliable, durable, and versatile solution for both industrial and commercial needs, ensuring long-lasting performance even in the most demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
